Description
2-20Nm / 1.5-15ft.lb / 18-180in.lb.
Length: 226mm.
Torque wrench weight: 442g.
Torque wrench weight with box: 867g.
4 measuring modes (torque, angle, torque backed up by angle, angle backed up by torque).
High-definition colour display with additional side-mounted indicator lamps.
Freely configurable menu structure.
Optionally: Li-ion battery No.7195-2 and charger No.7160.
3 function modes: cut out, peak hold (indicating mode with peak value) and track (indicating mode with current value).
Micro USB interface.
Bayonet connection for battery compartment.
QuickRelease safety lock change system for insert tools.
Angle-controlled measurement without a reference arm.
Data storage (≤ 2500 tightening jobs).
As many as 200 joints can be programmed in up to 25 preset sequences.
Different tolerence limits can be set for each joint.
Acoustic and visual assessment of the joint.
Rapid, accurate setting via keypad.
The automatic keypad lock prevents inadvertent changes.
Overload protection by means of acoustic and visual signals and fail-safe system (clockwise).
Automatic notification of the next calibration date, either by the number of joints or the time interval.
Fully automated calibrating and adjusting using the perfectControl calibrating and adjusting unit No.7794-2 (torque) or 7794-3 (torque and angle).
Units of measure (Nm, ft.lb & in.lb).
Tightening torque is automatically corrected if a deviating extension is entered.
Immediately reusable after release.
Clockwise and anti-clockwise tightening – it may be necessary to refit the insert tool rotated through 180° for anticlockwise tightening in the cut-out mode.
Tactile and acoustic trigger signal.
Torque and angle are simultaneously visible.
All readings are independent of the point of application of force ( with sizes 1, 2 & 4).
Safe handling due to ergonomically designed handle (resistant to oils, grease, fuels, brake fluid and Skydrol).
2 certificates (torque, angle).
Supplied in sturdy plastic case (sizes 40-100 in steel case).
Design patent, patent.
Supplied with SENSOMASTER Basic software, USB cable, 4 AAA/LR03 micro batteries, 1.5V AAA, 1.2V micro NiMH rechargeable batteries can be used.
Display resolution, angle 0.1°.
Display deviation value, angle ±1% ±1 digit.
Display resolution, torque d 60 N.m: 0.01Nm, > 60 N.m: 0.1Nm.
Display deviation value, torque ±2%, ±1 digit.
Length: 226mm.
Torque wrench weight: 442g.
Torque wrench weight with box: 867g.
4 measuring modes (torque, angle, torque backed up by angle, angle backed up by torque).
High-definition colour display with additional side-mounted indicator lamps.
Freely configurable menu structure.
Optionally: Li-ion battery No.7195-2 and charger No.7160.
3 function modes: cut out, peak hold (indicating mode with peak value) and track (indicating mode with current value).
Micro USB interface.
Bayonet connection for battery compartment.
QuickRelease safety lock change system for insert tools.
Angle-controlled measurement without a reference arm.
Data storage (≤ 2500 tightening jobs).
As many as 200 joints can be programmed in up to 25 preset sequences.
Different tolerence limits can be set for each joint.
Acoustic and visual assessment of the joint.
Rapid, accurate setting via keypad.
The automatic keypad lock prevents inadvertent changes.
Overload protection by means of acoustic and visual signals and fail-safe system (clockwise).
Automatic notification of the next calibration date, either by the number of joints or the time interval.
Fully automated calibrating and adjusting using the perfectControl calibrating and adjusting unit No.7794-2 (torque) or 7794-3 (torque and angle).
Units of measure (Nm, ft.lb & in.lb).
Tightening torque is automatically corrected if a deviating extension is entered.
Immediately reusable after release.
Clockwise and anti-clockwise tightening – it may be necessary to refit the insert tool rotated through 180° for anticlockwise tightening in the cut-out mode.
Tactile and acoustic trigger signal.
Torque and angle are simultaneously visible.
All readings are independent of the point of application of force ( with sizes 1, 2 & 4).
Safe handling due to ergonomically designed handle (resistant to oils, grease, fuels, brake fluid and Skydrol).
2 certificates (torque, angle).
Supplied in sturdy plastic case (sizes 40-100 in steel case).
Design patent, patent.
Supplied with SENSOMASTER Basic software, USB cable, 4 AAA/LR03 micro batteries, 1.5V AAA, 1.2V micro NiMH rechargeable batteries can be used.
Display resolution, angle 0.1°.
Display deviation value, angle ±1% ±1 digit.
Display resolution, torque d 60 N.m: 0.01Nm, > 60 N.m: 0.1Nm.
Display deviation value, torque ±2%, ±1 digit.
